Micro magnetic powder brake

Feature：

1, The micro-miniature magnetic powder brake has the characteristics of small size, stable operation, simple

    installation and durability. It is a high-precision transmission element, which is widely used in textile, printing,

    packaging and other electronic equipment and industrial machinery.

2, Using DC24V direct current, it is safer to use,

    Uses include: tension control, buffer start, braking, dimensional dynamic positioning, high-speed response,

    simulated load, etc. Multi-purpose, available from 5rmin, the maximum speed is 1800r/min.

3, The miniature magnetic powder brake is a self-cooling brake of the extended shaft type, with high structural

    precision and high precision.

4, Due to its relatively small size, the inertia moment of the rotating part is effectively reduced, and the installation is

    convenient and simple, temperature-resistant and durable.

Note: in the state of idling, the idling torque should not exceed 3% of the rated torque at 1000r/min, and should not exceed 5% of the rated torque at 1800r/min. In the process of using the miniature magnetic powder brake, its torque can be adjusted up or down (adjusted within the rated range). At this time, the tension can be easily adjusted by using the tension controller (manual or semi-automatic), and the tension is accurate, stable and constant. .
